PM0603-82NJ-RC

BOURNS JW MILLER  PM0603-82NJ-RC  片式电感, 82nH 400mA 5% 1700MHz

82 nH 无屏蔽 绕线 器 400 mA 540 毫欧 0603（1608 公制）

得捷:
FIXED IND 82NH 400MA 540MOHM SMD

e络盟:
BOURNS JW MILLER  PM0603-82NJ-RC  片式电感, 82nH 400mA 5% 1700MHz

艾睿:
This chip PM0603-82NJ-RC surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 1.85 mm long, 1.2 mm tall and 1.25 mm deep. It has a tolerance of 5%. It has an inductance of 82n H. Its test frequency is 150M Hz, while its minimum self-resonant frequency is 1.7G Hz. This SMD inductor has a maximum DC current of 400m A with a maximum resistance of 540m Ohm. This device utilizes wirewound technology.

安富利:
Ind Chip Wirewound 82nH 5% 150MHz 34Q-Factor Alumina 400mA 0603 T/R

Verical:
Inductor Chip Wirewound 82nH 5% 150MHz 34Q-Factor Alumina 400mA 540mOhm DCR 0603 T/R

Newark:
# BOURNS JW MILLER  PM0603-82NJ-RC  Surface Mount High Frequency Inductor, PM0603 Series, 82 nH, 400 mA, 0603 [1608 Metric], Wirewound

MASTER:
Inductor RF Wirewound 0.082uH 5% 150MHz 34Q-Factor Alumina 0.4A 0.54Ohm DCR 0603 T/R

Electro Sonic:
Inductor RF Wirewound 0.082uH 5% 150MHz 34Q-Factor Alumina 0.4A 0.54Ohm DCR 0603 T/R
