SMD功率电感 SMD Power Inductors
1µH Unshielded Wirewound Inductor 7.5A 7mOhm Nonstandard
得捷:
FIXED IND 1UH 7.5A 7 MOHM SMD
立创商城:
1uH ±20% 7.5A 7mΩ
艾睿:
This power PM3316-1R0M-RC surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -55 °C to 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 12.9 mm long, 5.3 mm tall and 10.2 mm deep. It has an inductance of 1u H. This SMD inductor has a maximum DC current of 7.5 A with a maximum resistance of 7m Ohm. This device utilizes wirewound technology. It has a tolerance of 20%. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 137M Hz.
Chip1Stop:
Ind Power Wirewound 1uH 20% 1KHz 20Q-Factor Ferrite 7.5A T/R
Verical:
Inductor Power Wirewound 1uH 20% 1KHz 20Q-Factor Ferrite 7.5A 0.007Ohm DCR T/R
Newark:
# BOURNS JW MILLER PM3316-1R0M-RC Surface Mount Power Inductor, PM3316 Series, 1 µH, 7.5 A, 9 A, Unshielded, 7000 µohm
Electro Sonic:
Inductor Power Wirewound 1uH 20% 1KHz 20Q-Factor Ferrite 7.5A 7mOhm DCR T/R
额定电流 7.5 A
容差 ±20 %
电感 1 µH
自谐频率 137 MHz
Q值 20
屏蔽 No
电感公差 ±20 %
测试频率 10 MHz
电阻DC) 7 mΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 0.007 Ω
安装方式 Surface Mount
引脚数 2
封装 0.512" L x 0.374" W x 0.205" H 13.00mm x 9.50mm x 5.20mm
长度 13.0 mm
宽度 10 mm
高度 5.3 mm
封装 0.512" L x 0.374" W x 0.205" H 13.00mm x 9.50mm x 5.20mm
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2016/06/20
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PM3316-1R0M-RC Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
PM3316-1R0M 伯恩斯 | 类似代替 | PM3316-1R0M-RC和PM3316-1R0M的区别 |
SDR1005-1R0ML 伯恩斯 | 功能相似 | PM3316-1R0M-RC和SDR1005-1R0ML的区别 |
SDR1005-1R0M 伯恩斯 | 功能相似 | PM3316-1R0M-RC和SDR1005-1R0M的区别 |
