SHIELDED SMD功率电感 Shielded SMD Power Inductors
2.4µH Shielded Wirewound Inductor 9.2A 10mOhm Max Nonstandard
得捷:
FIXED IND 2.4UH 9.2A 10 MOHM SMD
艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power PM127SH-2R4N-RC surface mount inductor from Bourns to save valuable space. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 45MTyp Hz. This SMD inductor has a maximum DC current of 9.2 A with a maximum resistance of 10m Ohm. It has an inductance of 2.4u H. This product is 12.8 mm long, 8 mm tall and 12.8 mm deep. This device is made with bobbin core technology.
Verical:
Inductor Power Shielded Bobbin Core 2.4uH -20% to 40% 100KHz 20Q-Factor Ferrite 9.2A 0.01Ohm DCR T/R
Electro Sonic:
Inductor Power Shielded Bobbin Core 2.4uH -20% to 40% 100KHz 20Q-Factor Ferrite 9.2A 10mOhm DCR T/R
Win Source:
FIXED IND 2.4UH 9.2A 10 MOHM SMD / 2.4 µH Shielded Drum Core, Wirewound Inductor 9.2 A 10mOhm Max Nonstandard
