贴片功率电感 SMD Power Inductor
220µH Unshielded Wirewound Inductor 200mA 3.2Ohm Max Nonstandard
得捷:
FIXED IND 220UH 200MA 3.2OHM SMD
艾睿:
This power PM1608-221M-RC surface mount inductor from Bourns is ideal for applications where space is a major influence of circuit design. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 5.5MTyp Hz. This device is made with bobbin core technology. It has an inductance of 220u H. This SMD inductor has a maximum DC current of 200m A with a maximum resistance of 3.2 Ohm. It has a tolerance of 20%. This product is 6.6 mm long, 2.92 mm tall and 4.45 mm deep.
安富利:
Ind Power Bobbin Core 220uH 20% 100KHz 33Q-Factor Ferrite 200mA T/R
Verical:
Inductor Power Bobbin Core 220uH 20% 100KHz 33Q-Factor Ferrite 0.2A 3.2Ohm DCR T/R
Electro Sonic:
Inductor Power Bobbin Core 220uH 20% 100KHz 33Q-Factor Ferrite 200mA 3.2Ohm DCR T/R
Win Source:
FIXED IND 220UH 200MA 3.2OHM SMD / 220 µH Unshielded Drum Core, Wirewound Inductor 200 mA 3.2Ohm Max Nonstandard
