与中断逻辑的4通道IC和SMBus多路复用器 4-CHANNEL IC AND SMBus MULTIPLEXER WITH INTERRUPT LOGIC
Shrink the number of electrical lines with this multiplexer from Texas Instruments by selecting one of several input signals and forwarding the selected signal into a single line! Its maximum power dissipation is 400 mW. This device has a maximum power dissipation of 400 mW. This multiplexer has a minimum operating temperature of -40 °C and a maximum of 85 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2.3 V, while its maximum is 5.5 V. It is made in a 1 x 4:1 configuration.
电源电压DC 2.30V ~ 5.50V
触点类型 4PST
电路数 4
传送延迟时间 1.00 ns
耗散功率 400 mW
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 400 mW
电源电压 2.3V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.3 V
安装方式 Surface Mount
引脚数 20
封装 TVSOP-20
长度 5 mm
宽度 4.4 mm
高度 1.05 mm
封装 TVSOP-20
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PCA9544ADGVR TI 德州仪器 | 当前型号 | 当前型号 |
PCA9544APWR 德州仪器 | 完全替代 | PCA9544ADGVR和PCA9544APWR的区别 |
PCA9544APW 德州仪器 | 完全替代 | PCA9544ADGVR和PCA9544APW的区别 |
PCA9544ADWR 德州仪器 | 完全替代 | PCA9544ADGVR和PCA9544ADWR的区别 |
