Res POT 10KΩ 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
Model PC is a 22 mm square, single-turn panel control with a space saving slim package. Plastic bushing and plastic shaft are standard. Conductive plastic element.
* PCW1J-B24: 3⁄4" Shaft Length
* PCW1J-B28: 7⁄8" Shaft Length
* Operating Temperature Range: +1°C to +125°C
* Temperature Coefficient: ±1000 ppm/°C
* Rotational Life: 50K Cycles
* Power Rating: 0.75 Watts
* Resistance Tolerance: ±20%
欧时:
Potentiometer, 10 Kilohms,1 Turn,0.75W
贸泽:
Potentiometers 10K 20% Sq 22mm Single Turn
艾睿:
Res Conductive Plastic POT 10K Ohm 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
Allied Electronics:
Pot; Cnd Pl; Rest 10 Kilohms; PCB; 1 Turn; Linear; Pwr-Rtg 0.75W; Shaft Dia 0.25In
Jameco:
Resistor Pot 10k Ohm 20% 3/4 Watt 1 Turn 6.35mm Pin Through Hole
安富利:
Res POT 10K Ohm 20% 3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
Chip1Stop:
Res Conductive Plastic POT 10K Ohm 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
TME:
Potentiometer: shaft; single turn; 10kΩ; 0.75W; ±20%; 6.35mm; THT
Verical:
Res Conductive Plastic POT 10K Ohm 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
Newark:
# BOURNS PCW1J-B24-BAB103L Rotary Potentiometer, Panel Control, 10 kohm, 750 mW, ± 20%, Slimline Series, 1 Turns, Linear
MASTER:
Res Conductive Plastic POT 10K Ohm 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
Electro Sonic:
Res Conductive Plastic POT 10K Ohm 20% 0.75W3/4W 1Elec/1MechTurn 6.35mm 23.37 X 27.36mm Pin Panel Mount/Bracket Mount
