PIC18F6628/6723/8628/8723 8 位闪存微控制器### PIC18 微控制器
PIC18F6628/6723/8628/8723 8 位闪存
得捷:
IC MCU 8BIT 128KB FLASH 64TQFP
立创商城:
PIC18LF6723-I/PT
欧时:
PIC18F6628/6723/8628/8723 8 位闪存微控制器
贸泽:
8-bit Microcontrollers - MCU 128KB Flash 4KB RAM 1024 DataEE 12B ADC
e络盟:
The PIC18LF6723-I/PT is a baseline PIC18 family 8-bit powerful 200 nanosecond instruction execution yet easy-to-program CMOS flash based Microcontroller packs powerful PIC®RISC architecture. This product utilize a 12-bit program word and provide the right amount of features including 128kB of addressable program memory size, 3936bytes of data memory size, 54 general-purpose I/O pins, two comparators and 12-channel 12-bit analog-to-digital A/D converter. This device operates at a maximum frequency of 40MHz wide operating voltage of 2 to 5.5V.
艾睿:
With the PIC18LF6723-I/PT microcontroller from Microchip Technology, you can program a circuit to perform tasks that meet your desired specifications. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has a maximum clock speed of 40 MHz. Its flash program memory is 128KB. This is a 8 bit processor. This device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V. This device is based on the PIC core architecture. Its ADC resolution is 12.
Allied Electronics:
PIC18LF6723-I/PT; 8bit PIC Microcontroller; 40MHz; 128kb; 1024 B Flash; 64-Pin TQFP
安富利:
MCU 8-bit PIC18 PIC RISC 128KB Flash 3.3V 64-Pin TQFP Tray
Chip1Stop:
MCU 8-bit PIC RISC 128KB Flash 2.5V/3.3V/5V 64-Pin TQFP Tray
Newark:
8 Bit Microcontroller, Flash, PIC18LF6xxx, 40 MHz, 128 KB, 3.84 KB, 64 Pins, TQFP
DeviceMart:
IC PIC MCU FLASH 64KX16 64TQFP
电源电压DC 2.00V min
时钟频率 40.0 MHz
RAM大小 3936 B
位数 8
耗散功率 1000 mW
FLASH内存容量 128 KB
内存容量 128000 B
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 64
封装 TQFP-64
长度 10 mm
宽度 10 mm
高度 1.05 mm
封装 TQFP-64
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Tray
制造应用 Lighting, Medical, Motor Drive & Control, Security, Consumer Electronics, Industrial, Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC18LF6723-I/PT Microchip 微芯 | 当前型号 | 当前型号 |
PIC18F6723-I/PT 微芯 | 类似代替 | PIC18LF6723-I/PT和PIC18F6723-I/PT的区别 |
PIC18LF6723T-I/PT 微芯 | 类似代替 | PIC18LF6723-I/PT和PIC18LF6723T-I/PT的区别 |
