PC3H7A

Optocoupler DC-IN 1CH Transistor DC-OUT 4Pin Mini-Flat T/R

PC900V0NSZX Series

■ Description

PC900V0NSZX Series contains an IRED optically coupled to an OPIC chip.

It is packaged in a 6 pin DIP, available in SMT gullwing lead-form and Wide SMT gullwing lead-form option.

Input-output isolation voltagerms is 5.0kV.

■Features

1\. 6 pin DIP package

2\. Double transfer mold packageIdeal for Flow Soldering

3\. Normal OFF operation, open collector output

4\. TTL and LSTTL compatible output

5\. Operating supply voltage VCC: 3 to 15 V

6\. Isolation voltage Visorms: 5.0 kV

■Applications

1\. Programmable controllers

2\. PC peripherals

3\. Electronic musical instruments
