PIC24FJ128GA202-I/MM

MICROCHIP  PIC24FJ128GA202-I/MM  微控制器, 16位, 通用, PIC24FJxxxGAxxx, 32 MHz, 128 KB, 8 KB, 28 引脚, QFN-S

The is a high-performance PIC24F family eXtreme low power technology 16-bit Microcontroller packs powerful PIC®RISC architecture with up to 16 MIPS of performance at 3.3V. This product offer all of the advantages of the well recognized high-performance x16 architecture with standardized features including 128kB of addressable program memory size, 8192bytes of data memory size, 20 general-purpose I/O pins and 9-channel 10/12-bit analog-to-digital A/D converter. This device operates at a maximum frequency of 32MHz with wide operating voltage of 2 to 3.6V.

.

XLP Technology for Sleep current at low as 20nA

.

Brown-out reset BOR

.

Low voltage detection LVD

.

Power on reset POR

.

Watch dog timer WDT

.

Hardware RTCC

.

6-Channel DMA

.

nanoWatt XLP technology

.

Three comparators

.

Charge time measurement unit CTMU

.

Peripheral pin select PPS

.

6x Capture/Compare/PWM CCP

.

Hardware encryption

.

Five 16-bit timers

.

Two 32-bit timers
