PIC24EP256GP202-I/SP

MICROCHIP  PIC24EP256GP202-I/SP.  芯片, 微控制器, 16位, PIC24, 70MIPS, SPDIP-28

The is a general purpose PIC24E family highest performance and excellent code density 16-bit Microcontroller packs powerful PIC®RISC architecture with up to 70 MIPS of performance at 3.3V. This product offer all of the advantages of the well recognized high-performance x16 architecture with standardized features including 256kB of addressable program memory size, 32768bytes of data memory size, 21 general-purpose I/O pins, 6-channel 10/12-bit analog-to-digital A/D converter and one 4-bit digital-to-analog D/A converter. This device operates at a maximum frequency of 70MHz with wide operating voltage of 3 to 3.6V.

.

Single cycle execution and fast interrupts 5 cycles

.

Brown-out reset BOR

.

Power on reset POR

.

Watch dog timer WDT

.

4-Channel DMA

.

Three comparators

.

2x Operational amplifier

.

Charge time measurement unit CTMU

.

Peripheral trigger generator PTG

.

Peripheral pin select PPS

.

Local interconnect network LIN

.

IrDA

.

Parallel port GPIO

.

Five 16-bit timers

.

Two 32-bit timers

.

Programmable Cyclic Redundancy Check CRC
