PX0635

BULGIN  PX0635  圆形连接器, General Purpose系列, 插头, 6 触点, 公, 焊接, 面板安装

6 路极化插头和插座

6 极设备入口，设计用于工业应用。 电缆插座采用酚醛和玻璃填充尼龙制模，带全屏蔽触点和一个电缆应力消除件。 插头和插座均具有焊接端接和一个内部钥匙路，可确保在配接时正确极化。

触点材料 | 镀银黄铜

---|---

最大额定值 | 3A 250V 交流

触点电阻 | <10mΩ

绝缘电阻 | >104MΩ

工作温度 | -20°C 至 +60°C

最大缆线直径 | 4mm

欧时:
6 way polarised chassis plug,3A 250Vac

得捷:
CONN RCPT MALE 6P SOLDER CUP

e络盟:
圆形连接器, General Purpose系列, 面板安装插头, 6 触点, 焊接引脚, 尼龙聚酰胺, 玻璃填充主体

艾睿:
Make a solid connection with this PX0635 connector from Bulgin Components. This male connector&s;s 6 contacts that are made out of brass and plated with silver. It has a straight body orientation. This device has a maximum current rating of 3 A. It uses the solder bucket termination method. This product is 34.1 mm long, 25.6 mm tall and 23.8 mm deep with a diameter of 25.6 mm. This circular connector has an operating temperature of -20 to 60 °C.

Allied Electronics:
Power Connector Panel Mount, Solder Termination, 3A, 50 V ac

Chip1Stop:
Conn Circular M 6 POS Solder Bucket ST Panel Mount 6 Terminal 1 Port

Newark:
# BULGIN  PX0635  Circular Connector, General Purpose Series, Plug, 6, Pin, Solder, Panel Mount

力源芯城:
6P圆形公座,焊接端子
