Contactor, IEC, Electro Mechanical, 12A, 220-240VAC Coil, 3PST-NO-DM, PBC Series
The PBC Series IEC-Type three pole contactor offers normally open, double make contacts in AC-3 ratings for 9 through 80 amps. Each contactor is also equipped with auxiliary contacts rated 360VA for AC-15 loads and 33 watts for DC-13 loads. The PBC series features finger-safe terminals and efficient 50/60 hertz coils. The contactor’s base is designed to mount on a DIN rail or directly to a panel. The modular design of the PBC allows it to readily accept various accessories. PBC models are UL Listed for the U.S. and Canada, and they are CE marked.
**Features**
* Three Pole Switching Main Contacts Plus Integral Auxiliary Contacts
* Designed to Snap onto DIN Rail or Mount Directly to a Panel with Screws
* Efficient 50/60 Hz Coils 50 Hz or 60 Hz Coils Optional
* Finger-Safe IP 20 Terminals
* Modular Design Allows Contactors and Accessories to Snap Together
* Comply with IEC EN60947-4-1 & EN60947-5-1; UL508; CSA22.2 No. 14
额定电流 12 A
额定功率 7.5 kW
触点类型 3PST-NO
触点额定电流 12 A
线圈电压 220 VAC
线圈电压AC 240 V
额定电流Max 25 A
线圈功率 9.4 VA
工作温度Max 40 ℃
工作温度Min -5 ℃
额定电压AC Max 690 V
安装方式 DIN Rail, DIN Panel
长度 75 mm
宽度 47 mm
高度 82 mm
触点材质 Silver Cadmium Oxide
工作温度 -5℃ ~ 40℃
产品生命周期 Obsolete
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536490075
