PFE850-12-054RA概述
AC-DC CONVERTER 12V 5V 850W
The PFE Series is a 600-1100 Watt power-factor-corrected PFC power supply with both AC and DC input and forward and reverse airflow versions. The PFE Series converts main power into an output 12 VDC for power Intermediate BUS Architecture IBA in high performance and reliability servers, routers, and network switches. The PFE Series meets international safety standards and displays the CE Mark for the European Low Voltage Directive LVD.- .
- *
Features
**
* Best-in-Class, 80 PLUS Certified “Platinum” Efficiency**
**
* Wide Input Voltage Range: 90-264 VAC**
**
* AC Input with Power Factor Correction**
**
* Always-On 16.5 W Programmable Standby Output 3.3/5 V**
**
* Hot-Plug Capable**
**
* Parallel Operation with Active Digital Current Sharing**
**
* Full Digital Controls for Improved Performance**
**
* High Density Design: 25.6 W/in.3**
**
* Small Form Factor: 54.5 × 40.0 × 321.5 mm**
**
* I2C Communication Interface for Control, Programming and Monitoring with PSMI and PMBus™ Protocol**
**
* Overtemperature, Output Overvoltage and Overcurrent Protection**
**
* 256 Bytes of EEPROM for User Information**
**
* 2 Status LEDs: AC OK and DC OK with Fault Signaling
