MICROCHIP PIC16F1459-I/ML 微控制器, 8位, 闪存, PIC16F145x, 48 MHz, 14 KB, 1 KB, 20 引脚, QFN
The is an enhanced mid-range PIC16 family 8-bit powerful 200 nanosecond instruction execution yet easy-to-program CMOS flash based Microcontroller packs powerful PIC®RISC architecture. This product offer all of the advantages of the well recognized mid-range x14 architecture with standardized features including 14kB of addressable program memory size, 1024bytes of data memory size, 18 general-purpose I/O pins, two comparators, 9-channel 10-bit analog-to-digital A/D converter and one 5-bit digital-to-analog D/A converter. This device operates at a maximum frequency of 48MHz with wide operating voltage of 1.8 to 5.5V.
频率 48 MHz
电源电压DC 2.50V min
工作电压 2.3V ~ 5.5V
针脚数 20
时钟频率 48 MHz
RAM大小 1 KB
位数 8
耗散功率 800 mW
模数转换数ADC 1
输入/输出数 17 Input
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 800 mW
数模转换数DAC 1
电源电压Max 5.5 V
电源电压Min 2.5 V
安装方式 Surface Mount
引脚数 20
封装 QFN-20
长度 4 mm
宽度 4 mm
高度 1 mm
封装 QFN-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 Lighting, 工业, 照明, 车用, 医用, 安全, Industrial, Security, Motor Drive & Control, Automotive, 电机驱动与控制, 消费电子产品, Consumer Electronics, Medical
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 3A991.a.2
HTS代码 8542310001
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC16F1459-I/ML Microchip 微芯 | 当前型号 | 当前型号 |
PIC16F1459T-I/ML 微芯 | 类似代替 | PIC16F1459-I/ML和PIC16F1459T-I/ML的区别 |
