14KB, 1KB RAM, HEF, 16B PWM, Comparator, 10B ADC, 5B DAC, CWG, PPS, EUSART
* Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels * Flash Program Memory with self read/write capability * High Endurance Flash memory in lower byte of last 128 addresses of Program Memory 100,000 Writes min. * Internal clock speeds from 31kHz to 32MHz * 4x Standalone 16-bit PWMs * Complementary Waveform Generator CWG * 8 Channel 10-bit ADC with Voltage Reference * 5-bit Digital to Analog Converter DAC * 2x Comparator * 2x 8-bit Timers TMR0/TMR2 * 1x 16-bit Timer TMR1 * Four additional 16-bit Timers available using the 16-bit PWMs * Extended Watchdog Timer WDT * Enhanced Power-On/Off-Reset * Low-Power Brown-Out Reset LPBOR * Programmable Brown-Out Reset BOR * In Circuit Serial Programming ICSP * Wide Operation Voltage Variant ‘F’ 2.3V – 5.5V * eXtreme Low Power XLP ‘LF’ Variant 1.8V – 3.6V
