MICROCHIP PIC16C715-20/P 微控制器, 8位, 一次性可编程, PIC16C, 20 MHz, 3.5 KB, 128 Byte, 18 引脚, DIP
The is a PIC16 family 8-bit powerful 200 nanosecond instruction execution yet easy-to-program only 35 single word instructions CMOS one-time programmable OTP based Microcontroller packs powerful PIC®RISC architecture. This product offer all of the advantages of the well recognized mid-range x14 architecture with standardized features including 3.5kB of addressable program memory size, 128bytes of data memory size, 13 general-purpose I/O pins and 4-channel 8-bit analog-to-digital A/D converter. This device operates at a maximum frequency of 20MHz with wide operating voltage of 2.5 to 5.5V.
频率 20 MHz
电源电压DC 5.00 V, 5.50 V max
工作电压 2.5V ~ 5.5V
针脚数 18
时钟频率 20 MHz
RAM大小 128 B
位数 8
耗散功率 1000 mW
I/O引脚数 13
存取时间 20.0 µs
内核架构 PIC
内存容量 2000 B
模数转换数ADC 1
输入/输出数 13 Input
工作温度Max 70 ℃
工作温度Min 0 ℃
耗散功率Max 1000 mW
电源电压 2.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.5 V
安装方式 Through Hole
引脚数 18
封装 DIP-18
长度 22.86 mm
宽度 6.35 mm
高度 3.3 mm
封装 DIP-18
工作温度 0℃ ~ 70℃
产品生命周期 Unknown
包装方式 Tube
制造应用 Security, 消费电子产品, 工业, 车用, Lighting, Industrial, Medical, 照明, Consumer Electronics, Automotive, 安全, 医用, 电机驱动与控制, Motor Drive & Control
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC16C715-20/P Microchip 微芯 | 当前型号 | 当前型号 |
PIC16F716-I/P 微芯 | 类似代替 | PIC16C715-20/P和PIC16F716-I/P的区别 |
PIC16C715-04/P 微芯 | 类似代替 | PIC16C715-20/P和PIC16C715-04/P的区别 |
PIC16C715-20I/P 微芯 | 类似代替 | PIC16C715-20/P和PIC16C715-20I/P的区别 |
