PXM7010/10P/CR/0911

PXM7010/10P/CR/0911图片1
PXM7010/10P/CR/0911图片2
PXM7010/10P/CR/0911图片3
PXM7010/10P/CR/0911图片4
PXM7010/10P/CR/0911概述

Connector; Flex; 10Pole; Male/Pin; Crimp Term.; 9-11mm Cable Entry; Metal

The all metal construction 7000 Series Buccaneer® - circular connectors that combine the ease of use of a quick coupling mechanism with proven environmental sealing for signal and mains power. Designed and independently tested to IP66, IP68 & IP69K standards, they are ideal for applications where ingress of dust and water must be avoided and where ease of connection, space and appearance are important considerations.


得捷:
CONN PLG HSG MALE 10POS INLINE


艾睿:
Conn Circular PIN 10 POS Crimp ST Cable Mount 10 Terminal 1 Port Buccaneer® Bulk


Allied Electronics:
Connector; Flex; 10-Pole; Male/Pin; Crimp Term.; 9-11mm Cable Entry; Metal


PXM7010/10P/CR/0911中文资料参数规格
技术参数

触点数 10

极性 Male

绝缘电阻 1000000 MΩ

针脚数 10

额定电流Max 10 A

工作温度Max 120 ℃

工作温度Min -40 ℃

额定电压Max 600 V

接触电阻Max 10 mΩ

物理参数

外壳颜色 Silver

触点材质 Brass

工作温度 -40℃ ~ 120℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买PXM7010/10P/CR/0911
型号: PXM7010/10P/CR/0911
制造商: Bulgin Components 布尔金原器件
描述:Connector; Flex; 10Pole; Male/Pin; Crimp Term.; 9-11mm Cable Entry; Metal
