直流-直流转换器, 隔离 POL, 1 输出, 15.6W,
Provide the ability to switch between voltages by using this step down DC to DC converter and switching regulator module. It has a voltage of 12 V. This part has a temperature range of -40 °C to 85 °C.
得捷:
DC DC CONVERTER 12V 15W
贸泽:
隔离式DC/DC转换器 15W 12V 1.3A
e络盟:
直流-直流转换器, 隔离 POL, 1 输出, 15.6W,
艾睿:
Provide the ability to switch between voltages by using this step down PXB15-48WS12/NT DC to DC converter and switching regulator module. It has a voltage of 12 V. This part has a temperature range of -40 °C to 85 °C.
Chip1Stop:
Module DC-DC 48VIN 1-OUT 12V 1.3A 15.6W 6-Pin
Verical:
Module DC-DC 48VIN 1-OUT 12V 1.3A 15.6W 6-Pin
电源电压DC 48.0 V
额定功率 15 W
输出接口数 1
输入电压DC 18V ~ 75V
输出电压 12 V
输出电流 1.3 A
输出功率 15 W
隔离电压 1.6 kV
输入电压Max 75 V
输入电压Min 18 V
输入电压DC Max 75 V
输入电压DC Min 18 v
输出电流Max 1.3 A
输出功率Max 15.6 W
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 18V ~ 75V
安装方式 Through Hole
引脚数 6
封装 DIP-6
长度 1 in
宽度 1 in
高度 9.91 mm
封装 DIP-6
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
