PQ1LA333MSPQ LDO电压调整器/稳压电源IC 3.3V 300mV/0.3V 带使能脚EN/CE SOT89-5 marking/标记 L33 短路保护 过热保护
Compact Surface Mount Type, Low Output Current, Low Power-Loss Voltage Regulators ;•Compact surface mount package SOT-89 4.5×4.3×1.5 mm •Output current : MAX.300mA •Power dissipation : MAX.900mW •Low power-lossDropout voltage : MAX.0.7 V at IO=300mA •High ripple rejection TYP. 70dB •Built-in output ON/OFF control function •CD-ROM drives •DVD-ROM drives •Digital Still Cameras
得捷:
IC REG LINEAR 3.3V 300MA SOT89
贸泽:
低压差稳压器 LDO 3.3V0.3A
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 300mA SOT-89
输入电压DC 15.0V max
输出电压 3.3 V
输出电流 300 mA
耗散功率 0.9 W
跌落电压 0.4V @300mA
输入电压Max 15 V
输入电压Min 2.5 V
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 ≤15 V
安装方式 Surface Mount
封装 SOT-89-5
长度 4.5 mm
宽度 2.5 mm
高度 1.5 mm
封装 SOT-89-5
工作温度 -40℃ ~ 85℃
产品生命周期 Obsolete
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
