PCD 系列 25.2 W 1.40 A 相位调光 驱动器 北美版
1.4A 12 ~ 18V 恒定电流 LED 驱动器 AC DC 转换器 拓扑 输出
得捷:
LED DRIVER CC AC/DC 12-18V 1.4A
贸泽:
LED电源 25.2W 12-18Vout 1400mA 90-135VAC
艾睿:
Ensure optimal performance of your electronic device with the use of this PCD-25-1400A AC to DC power supply from Mean-Well USA, Inc.. It has a voltage of 12 to 18 V and maximum output power of 25.2 W. This part&s;s single output can handle a current up to 1.4 A. This part has a temperature range of -30 °C to 60 °C.
Allied Electronics:
Power Supply; AC-DC; 18V@1.4A; 90-135V In; Enclosed; Panel Mnt; LED Driver; PCD Series
Jameco:
Enclosed Switching LED Power Supply 12 to 18 Volts 1.4 Amps 25.2 Watts Phase Dimmer
Chip1Stop:
AC/DC Power Supply Single-OUT 12V to 18V 1.4A 25.2W 4-Pin
MASTER:
AC/DC LED Power Sply - Const Curr - 25.2W - Dim:25 Vdc OC @ 1,400mA - Dim: AC Line Phase Cut
Online Components:
AC/DC Power Supply Single-OUT 12V to 18V 1.4A 25.2W 4-Pin , Useable w/some AC Wall Dimmers
Electro Sonic:
AC/DC LED Power Sply - Const Curr - 25.2W - Dim:25 Vdc OC @ 1,400mA - Dim: AC Line ...
CDI:
LED Driver CC 25W 1400mA Linear 12-18Vdc 90-135Vac PFC Phase-Cut Dimming IP30 Plastic Enclosure
频率 63 Hz
额定功率 25 W
输出接口数 1
输出电压 12V ~ 18V
输出电流 1.4 A
输入电流 0.6 A
输出功率 25.2 W
隔离电压 3.75 kV
输入电压Max 135 VAC
输入电压Min 90 VAC
输出电流Max 1400 mA
输入电流Min 0.6 A
输出功率Max 25.2 W
工作温度Max 60 ℃
工作温度Min -30 ℃
输入电压 90VAC ~ 135VAC
安装方式 Screw
引脚数 4
封装 Plastic Enclosure
长度 84 mm
宽度 57 mm
高度 29.5 mm
封装 Plastic Enclosure
工作温度 -30℃ ~ 60℃
产品生命周期 Active
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409510
