TRANSZORB® 瞬态电压抑制器轴向单向 600W，Vishay Semiconductor### 瞬态电压抑制器，Vishay Semiconductor
TRANSZORB® 瞬态电压抑制器轴向单向 600W，Vishay Semiconductor
### 瞬态电压抑制器，Vishay Semiconductor
立创商城:
Vrwm:11.1V 600W
欧时:
TVS 二极管 Vishay P6KE13A-E3/54 单向, 600W, 18.2V, 2针 DO-204AC封装
艾睿:
This P6KE13A-E3/54 TVS diode developed by Vishay can help protect your expensive equipment and electronics. This device&s;s maximum clamping voltage is 18.2 V and minimum breakdown voltage is 12.4 V. Its peak pulse power dissipation is 600 W. Its test current is 1 mA. Its maximum leakage current is 5 μA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively.
安富利:
Diode TVS Single Uni-Dir 11.1V 600W 2-Pin DO-15 T/R
Win Source:
TVS DIODE 11.1VWM 18.2VC DO204AC
工作电压 11.1 V
击穿电压 12.4 V
耗散功率 600 W
钳位电压 18.2 V
最大反向电压（Vrrm） 13V
测试电流 1 mA
最大反向击穿电压 12.4V-13.7V
脉冲峰值功率 600 W
最小反向击穿电压 12.4 V
工作温度Max 175 ℃
工作温度Min -55 ℃
工作结温 -55℃ ~ 175℃
安装方式 Through Hole
引脚数 2
封装 DO-204AC
长度 7.6 mm
封装 DO-204AC
工作温度 -55℃ ~ 175℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
RoHS标准
含铅标准 Lead Free
