YAGEO PHYCOMP RC0402FR-07910RL 片式电阻器, 表面贴装, 厚膜, RC系列, 910 ohm, 50 V, 0402 [1005公制], 63 mW, ± 1%
SMD器/芯片电阻器
得捷:
RES 910 OHM 1% 1/16W 0402
立创商城:
910Ω ±1% 62.5mW
e络盟:
SMD片式电阻, 厚膜, 0402 [1005公制], 910 ohm, RC系列, 50 V, 厚膜, 63 mW
艾睿:
Use this RC0402FR-07910RL fixed single surface-mount resistor from Yageo to obtain a visually clean layout. This product has a resistance value of 910 Ohm. This dependable part has a power rating of 0.063 1/16 W. Its temperature coefficient is ±100 ppm/°C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a tolerance of 1%. This part has an operating temperature of -55 to 155 °C. This product is 1 mm long, 0.35 mm tall and 0.5 mm deep. This device utilizes thick film technology.
Chip1Stop:
Res Thick Film 0402 910 Ohm 1% 1/16W ±100ppm/℃ Molded SMD Paper T/R
Verical:
RC0402FR-07910RL
Newark:
# YAGEO PHYCOMP RC0402FR-07910RL Surface Mount Chip Resistor, Thick Film, RC Series, 910 ohm, 63 mW, 1%, 50 V, 0402 [1005 Metric]
儒卓力:
**RC0402 910R 1% 0,063W TK100 **
额定电压DC 50.0 V
容差 ±1 %
额定功率 0.063 W
产品系列 RC
电阻 910 Ω
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
额定电压 50 V
安装方式 Surface Mount
引脚数 2
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.35 mm
封装公制 1005
封装 0402
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Cut Tape CT
最小包装 10000
制造应用 工业, Industrial, 电源管理, 便携式器材, Consumer Electronics, Power Management, 消费电子产品, Portable Devices
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
RC0402FR-07910RL Yageo 国巨 | 当前型号 | 当前型号 |
9C04021A9100FLHF3 国巨 | 完全替代 | RC0402FR-07910RL和9C04021A9100FLHF3的区别 |
RC0402JR-07910RL 国巨 | 类似代替 | RC0402FR-07910RL和RC0402JR-07910RL的区别 |
CRCW0402910RFKED 威世 | 功能相似 | RC0402FR-07910RL和CRCW0402910RFKED的区别 |
