2W DC/DC-转换器 "ECONOLINE" SMD 1KV 未稳压
隔离模块 直流转换器 1 输出 5V - - 400mA 4.5V - 5.5V 输入
得捷:
DC DC CONVERTER 5V 2W
艾睿:
Look no further than RECOM&s;s R2S-0505-R DC to DC converter and switching regulator module, a device that can step above or below input levels. It has a voltage of 5 V. This part has a minimum operating temperature of -40 °C and a maximum of 100 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components.
Chip1Stop:
Module DC-DC 1-OUT 5V 0.4A 2W 5-Pin SMD T/R
Newark:
# RECOM POWER R2S-0505-R Isolated Board Mount DC/DC Converter, Medical, Fixed, 1 Output, 4.5 V, 5.5 V, 2 W, 5 V
额定功率 2 W
输出接口数 1
输出电压 5 V
输出电流 0.4 A
输出功率 2 W
隔离电压 1 kV
开关频率 85 kHz
输入电压Max 5.5 V
输入电压Min 4.5 V
输入电压DC Max 5.5 V
输入电压DC Min 4.5 v
输出电流Max 400 mA
输出功率Max 2 W
工作温度Max 100 ℃
工作温度Min -40 ℃
输入电压 5V ~ 5V
安装方式 Surface Mount
引脚数 5
封装 SMD-8
长度 0.5 in
宽度 10.7 mm
高度 8.7 mm
封装 SMD-8
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 ITE(商业), 医用型
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
R2S-0505-R RECOM Power | 当前型号 | 当前型号 |
R2S-0505 RECOM Power | 类似代替 | R2S-0505-R和R2S-0505的区别 |
RTS-0505-R RECOM Power | 类似代替 | R2S-0505-R和RTS-0505-R的区别 |
