RAM-1205S

Recom ECONOLINE 1W SMD Unregulated Medical Isolated DC/DC Converter - RAM SeriesECONOLINE RAM series 1W SMD unregulated, isolated, single output DC/DC converters with a 1.1 input range and EN60601-1 medical approval. These SMD unregulated medical DC/DC converters have an extended operating temperature range of -40 to +100°C without derating and 3kVDC isolation.1:1 input voltage range EN60601-1 approved for medical applications Up to 80% efficiency 3kVDC isolation -40 to +100°C operating temperature range without derating Continuous short circuit protection ### 注MTBF: MIL-HDBK 217F 25% For EMC compliance please see datasheet### 标准EN-60601-1, UL-60950-1### Recom - SMD 1W 至 5W

Recom ECONOLINE 1W SMD 非稳压医学用隔离式直流/直流转换器 - RAM 系列

ECONOLINE RAM 系列 1W SMD 非稳压隔离式单输出直流/直流转换器具有 1.1 的输入范围且通过 EN60601-1 医疗认证。这些 SMD 非稳压医疗用直流/直流转换器可在更大的温度范围（-40 至 +100°C）内工作而不会降额运行并具有 3kVDC 的隔离能力。

1:1 输入电压范围

经过 EN60601-1 认证，可用于医学器械

效率高达 80%

3kVDC 隔离能力

-40 至+100°C 工作温度范围，不会降低

持续的短路保护

### 注

MTBF：MIL-HDBK 217F 25%

有关 EMC 合规性请参见数据表

### 标准

EN-60601-1，UL-60950-1

得捷:
DC DC CONVERTER 5V 1W

欧时:
Recom 1W 隔离式直流-直流转换器 RAM-1205S, 10.8 → 13.2 V 直流输入, 5V dc输出, 200mA输出

贸泽:
Isolated DC/DC Converters 1W 12VIN 05VOUT 3kVDC ISO

艾睿:
DC/DC-CONVERTER 3KVDC AND 4KVDC ISOLATION OPTION

Allied Electronics:
DC/DC converter, Isolated, Medical, 5V, 1W

Chip1Stop:
DC/DC-CONVERTER 3KVDC AND 4KVDC ISOLATION OPTION

Newark:
# RECOM POWER  RAM-1205S  Isolated Board Mount DC/DC Converter, Medical, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 5 V
