2W DC/DC-转换器 "ECONOLINE" SMD 1KV 未稳压
隔离模块 直流转换器 输出 5V - - 400mA 10.8V - 13.2V 输入
得捷:
DC DC CONVERTER 5V 2W
艾睿:
Provide the ability to switch between voltages by using this step down R2S-1205-R DC to DC converter and switching regulator module. It has a voltage of 5 V. This part has a minimum operating temperature of -40 °C and a maximum of 100 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment.
Chip1Stop:
Module DC-DC 1-OUT 5V 0.4A 2W 5-Pin SMD T/R
Newark:
# RECOM POWER R2S-1205-R Isolated Board Mount DC/DC Converter, Medical, Fixed, 1 Output, 10.8 V, 13.2 V, 2 W, 5 V
儒卓力:
**DC/DC-CONV. 12V TO 5V 2W 1kV **
额定功率 2 W
输出接口数 1
输出电压 5 V
输出电流 0.4 A
输出功率 2 W
隔离电压 1 kV
开关频率 85 kHz
输入电压Max 13.2 V
输入电压Min 10.8 V
输入电压DC Max 13.2 V
输入电压DC Min 10.8 v
输出电流Max 400 mA
输出功率Max 2 W
工作温度Max 100 ℃
工作温度Min -40 ℃
输入电压 12V ~ 12V
安装方式 Surface Mount
引脚数 5
封装 SMD-8
宽度 10.7 mm
高度 8.7 mm
封装 SMD-8
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 医用型, ITE(商业)
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
R2S-1205-R RECOM Power | 当前型号 | 当前型号 |
RTS-1205-R RECOM Power | 完全替代 | R2S-1205-R和RTS-1205-R的区别 |
R2S-1205 RECOM Power | 类似代替 | R2S-1205-R和R2S-1205的区别 |
