R412410000概述
RADIALL R412410000. 射频/同轴连接器, BNC同轴, 50 ohm, 铍铜
The . is a 2GHz 10dB BNC Attenuator with gold over nickel plated beryllium copper contacts and nickel-plated brass body. This attenuator has PTFE insulation, thin film resistor, worldwide standardised coaxial connectors, bayonet coupling and good RF performance.
- .
- Proven strength and reliability
- .
- Meets MIL-C-39012/MIL STD 348-A/301, IEC 169-8, CECC 22120 and UTE-C-93564 standards
- .
- 50R Nominal impedance
- .
- 100W Peak power
- .
- 2W Average power
- .
- -55 to 125°C Temperature range
R412410000中文资料参数规格
技术参数
触点电镀 Gold
额定功率 2.00 W
额定功率Max 100 W
物理参数
触点材质 Beryllium Copper
工作温度 -55℃ ~ 125℃
其他
产品生命周期 Active
制造应用 Military, RF Communications, 军用与航空, Test & Measurement, Consumer Electronics, 工业, 通信与网络, Defence, 消费电子产品, Communications & Networking, 射频通信, Industrial, Aerospace, 国防, 测试与测量
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 Yes
