60 W 单输出 12 V 短路保护 AC/DC 电源
Power your device with direct current by using this AC to DC power supply from RECOM to convert an alternating current source to a direct current supply. It has a voltage of 12 V and maximum output power of 60 W. This part"s single output can handle a current up to 5 A. This part has a temperature range of -40 °C to 70 °C.
得捷:
AC/DC CONVERTER 12V 60W
艾睿:
Power your device with direct current by using this RAC60-12SB AC to DC power supply from RECOM to convert an alternating current source to a direct current supply. It has a voltage of 12 V and maximum output power of 60 W. This part&s;s single output can handle a current up to 5 A. This part has a temperature range of -40 °C to 70 °C.
富昌:
60 W 单输出 12 V 短路保护 AC/DC 电源
Chip1Stop:
AC/DC Power Supply Single-OUT 12V 5A 60W 6-Pin
Newark:
# RECOM POWER RAC60-12SB AC/DC PCB Mount Power Supply, Medical, Adjustable, 1 Output, 85 V, 265 V, 60 W, 12 V
额定功率 60 W
输出接口数 1
输出电压 12 V
输出电流 5 A
输出功率 60 W
隔离电压 4 kV
输入电压DC Max 370 V
输入电压DC Min 100 V
输入电压AC Max 265 v
输入电压AC Min 85 v
输出电流Max 5 A
输入电流Min 2 A
输出功率Max 60 W
额定功率Max 60 W
工作温度Max 70 ℃
工作温度Min -40 ℃
输入电压 85V ~ 265VAC
安装方式 Through Hole
引脚数 6
封装 DIP-6
长度 109 mm
宽度 58.5 mm
高度 109 mm
封装 DIP-6
重量 310.26 g
工作温度 -40℃ ~ 70℃
产品生命周期 Active
包装方式 Box
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
