RENESAS R5F61622N50FPV 32Bit Microcontroller, H8SX, 50MHz, 256KB, 24KB, 144Pins, LQFP
H8SX H8® H8SX/1600 Microcontroller IC 32-Bit 50MHz 256KB 256K x 8 FLASH 144-LFQFP 20x20
得捷:
IC MCU 32BIT 256KB FLSH 144LFQFP
艾睿:
Use this programmable R5F61622N50FPV microcontroller manufactured by Renesas, to dress up any design. This microcontroller has an operating temperature range of -20 °C to 75 °C. It has a maximum clock speed of 50 MHz. Its flash program memory is 256KB. This is a 32 bit processor. Its ADC resolution is 10, while its DAC resolution is 8. This device has a typical operating supply voltage of 3.3 V. Its minimum operating supply voltage of 3 V, while its maximum is 3.6 V.
安富利:
MCU 32-bit H8S CISC 256KB Flash 3.3V 144-Pin LQFP
Chip1Stop:
MCU 32-Bit H8S CISC 256KB Flash 3.3V 144-Pin LQFP
Verical:
MCU 32-bit H8S CISC 256KB Flash 3.3V 144-Pin LQFP
DeviceMart:
MCU 24KB FLASH 256K ROM 144-LQFP
频率 50 MHz
时钟频率 50.0 MHz
RAM大小 24 KB
位数 16, 32
FLASH内存容量 1 KB
模数转换数ADC 1
工作温度Max 75 ℃
工作温度Min -20 ℃
数模转换数DAC 1
电源电压Max 3.6 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 144
封装 LQFP-144
封装 LQFP-144
工作温度 -20℃ ~ 75℃ TA
产品生命周期 Unknown
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
