RAYCHEM - TE CONNECTIVITY RNF-100-MINI-SPL-3/64-BK Heat Shrink Tubing, Flame Retardant, 1.2mm, 0.046 ", 2:1, Black, 100Ft, 30.5m
Single Wall Tubing, Polyolefin Material, 2:1 Shrink Ratio
** Applications.** Designed to provide superior mechanical abrasion, cut-through, and strain relief, thermal and fluid-resistance performance in demanding environments. Widely used to provide insulation and strain relief of wire terminations and connections. Used for jacketing wire bundles and light-duty harnesses where superior abrasion resistance is a plus. Also used to identify and color-code electrical connections and wire bundles.
** Features**
* 2:1 Shrink Ratio
* Superior Abrasion and Solvent Resistance When Compared with That of Many Flexible, General Purpose Polyolefin Tubings
* Excellent Physical, Chemical and Electrical Properties That Meet or Exceed Industrial and Military Standards for Highly Reliable, General Purpose Tubing
* Flexible, Thin-Wall, Flame-Retardant Polyolefin Tubing
* UL Recognized, CSA Certified
* Minimum Shrink Temperature: 95°C
* Minimum Full Recovery Temp.: 121°C
* Operating Temperature Range: -55°C to 135°C
