SMD电阻器/芯片电阻器
SMD器/芯片电阻器
得捷:
RES 2.4M OHM 5% 1/4W 1206
立创商城:
2.4MΩ ±5% 250mW
贸泽:
Thick Film Resistors - SMD 2.4M OHM 5%
艾睿:
This is a RC1206JR-072M4L fixed single surface-mount resistor from Yageo. This product has a resistance value of 1.828 Ohm. This part has a power rating of 26 W. Its temperature coefficient is Crimp ppm/°C. This product is Gold Over Nickel mm tall. This device utilizes insulated wire technology. The RC1206JR-072M4L part has a 3 termination style. This part has an operating temperature of Copper Alloy °C. It is reliable with a failure rate grade of -55 to 150.
安富利:
Res Thick Film 1206 2.4M Ohm 5% 1/4W ±100ppm/°C Molded SMD SMD Paper T/R
TME:
Resistor: thick film; SMD; 1206; 2.4MΩ; 0.25W; ±5%; -55÷155°C
Verical:
Res Thick Film 1206 2.4M Ohm 5% 0.25W1/4W ±100ppm/C Pad SMD T/R
儒卓力:
**RC1206 2,4M 5% 0,25W **
额定电压DC 200 V
容差 ±5 %
额定功率 0.25 W
产品系列 RC
电阻 2.4 MΩ
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±5 %
额定电压 200 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.55 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 5000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
RC1206JR-072M4L Yageo 国巨 | 当前型号 | 当前型号 |
9C12063A2404JLHFT 国巨 | 完全替代 | RC1206JR-072M4L和9C12063A2404JLHFT的区别 |
RC1206JR-072M4 国巨 | 完全替代 | RC1206JR-072M4L和RC1206JR-072M4的区别 |
RC1206FR-072M4L 国巨 | 类似代替 | RC1206JR-072M4L和RC1206FR-072M4L的区别 |
