RC 系列 1206 0.25 W 487 ohm 1% ±100 ppm/°C 表面贴装 厚膜 贴片电阻
SMD器/芯片电阻器
得捷:
RES 487 OHM 1% 1/4W 1206
立创商城:
487Ω ±1% 250mW
艾睿:
The RC1206FR-07487RL fixed single surface-mount resistor from Yageo makes it easy to add resistors to your circuit board. This product has a resistance value of 487 Ohm. This durable part has a power rating of 0.25 1/4 W. Its temperature coefficient is ±100 ppm/°C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 3.1 mm long, 0.55 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 155 °C. It has a tolerance of 1%. This device is made with thick film technology.
安富利:
Res Thick Film 1206 487 Ohm 1% 1/4W ±100ppm/°C Molded SMD SMD Paper T/R
儒卓力:
**RC1206 487R 1% 0,25W **
Win Source:
RES 487 OHM 1% 1/4W 1206 / 487 Ohms ±1% 0.25W, 1/4W Chip Resistor 1206 3216 Metric Moisture Resistant Thick Film
额定电压DC 200 V
容差 ±1 %
额定功率 0.25 W
产品系列 RC
电阻 487 Ω
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.55 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 5000
RoHS标准
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
RC1206FR-07487RL Yageo 国巨 | 当前型号 | 当前型号 |
RC1206FR-07487R 国巨 | 完全替代 | RC1206FR-07487RL和RC1206FR-07487R的区别 |
9C12063A4870FKHFT 国巨 | 完全替代 | RC1206FR-07487RL和9C12063A4870FKHFT的区别 |
AR1206FR-07487RL 国巨 | 功能相似 | RC1206FR-07487RL和AR1206FR-07487RL的区别 |
