SMD电阻器/芯片电阻器
SMD器/芯片电阻器
得捷:
RES 31.6 OHM 1% 1/16W 0402
立创商城:
31.6Ω ±1% 62.5mW
艾睿:
The RC0402FR-0731R6L fixed single surface-mount resistor from Yageo makes it easy to add resistors to your circuit board. This part has a power rating of 0.063 1/16 W. This product has a resistance value of 31.6 Ohm. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This part has an operating temperature of -55 to 155 °C. It has a tolerance of 1%. This product is 1 mm long, 0.35 mm tall and 0.5 mm deep. This device utilizes thick film technology.
富昌:
RC Series 0402 0.063 W 31.6 Ohms ±1% ±100 ppm/°C SMT Thick Film Chip Resistor
Verical:
RC0402FR-0731R6L
儒卓力:
**RC0402 31,6R 1% 0,063W TK100 **
额定电压DC 50.0 V
容差 ±1 %
额定功率 0.063 W
产品系列 RC
电阻 31.6 Ω
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
安装方式 Surface Mount
封装公制 0402
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.35 mm
封装公制 0402
封装 0402
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
RC0402FR-0731R6L Yageo 国巨 | 当前型号 | 当前型号 |
AR0402FR-0731R6L 国巨 | 功能相似 | RC0402FR-0731R6L和AR0402FR-0731R6L的区别 |
