RL1206FR-7W0R15L

YAGEO PHYCOMP  RL1206FR-7W0R15L  片式电阻器, 表面贴装, 厚膜, RL系列, 0.15 ohm, 200 V, 1206 [3216公制], 500 mW, ± 1%

SMD器/芯片电阻器

得捷:
RES 0.15 OHM 1% 1/2W 1206

立创商城:
150mΩ ±1% 500mW

e络盟:
SMD片式电阻, 1206 [3216公制], 0.15 ohm, RL系列, 200 V, 厚膜, 500 mW

艾睿:
This is a RL1206FR-7W0R15L fixed single surface-mount resistor from Yageo. This product has a resistance value of 150m Ohm. This part has a power rating of 0.5 1/2 W. It is also complete with current sensing technology. Its temperature coefficient is ±600 ppm/°C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This part has an operating temperature of -55 to 125 °C. This device utilizes thick film technology. This product is 3.1 mm long, 0.55 mm tall and 1.6 mm deep. It has a tolerance of 1%.

TME:
Resistor: thick film; SMD; 1206; 150mΩ; 250mW; ±1%

Verical:
Res Thick Film 1206 0.15 Ohm 1% 0.5W1/2W ±600ppm/C Pad SMD T/R

Newark:
# YAGEO PHYCOMP  RL1206FR-7W0R15L  SMD Chip Resistor, Thick Film, 0.15 ohm, 200 V, 1206 [3216 Metric], 500 mW, ± 1%, RL Series

儒卓力:
**RC1206 0,15R 1% 0,5W **
