0.005Ω ±5% 1W
Res Wirewound 0.005 Ohm 5% 1W J-Lead SMD
得捷:
RES 0.005 OHM 5% 1W J LEAD
艾睿:
Res Wirewound 0.005 Ohm 5% 1W J-Lead SMD
Allied Electronics:
RES SMD 0.005 OHM 5% 1W J LEAD
Chip1Stop:
Res Wirewound 0.005 Ohm 5% 1W Molded J-Lead SMD
立创商城:
5mΩ ±5% 1W
Newark:
# OHMITE RW1S0BAR005JE SMD Current Sense Resistors, RW Series, 0.005 ohm, 1 W, - 5%, 50 V, 2413 [6234 Metric] New
MASTER:
Res Wirewound 0.005 Ohm 5% 1W J-Lead SMD
Online Components:
Res Wirewound 0.005 Ohm 5% 1W J-Lead SMD
Electro Sonic:
Res Wirewound 0.005 Ohm 5% 1W J-Lead SMD
额定电压DC 50.0 V
额定功率 1 W
产品系列 RW
电阻 5 mΩ
阻值偏差 ±5 %
工作温度Max 150 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
引脚数 2
封装公制 6432
封装 2413
长度 6.25 mm
宽度 3.45 mm
高度 3.45 mm
封装公制 6432
封装 2413
工作温度 -55℃ ~ 150℃
温度系数 ±90 ppm/℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8533210030
