RW2S0CB1R00JE

RW2S0CB1R00JE图片1
RW2S0CB1R00JE图片2
RW2S0CB1R00JE图片3
RW2S0CB1R00JE图片4
RW2S0CB1R00JE图片5
RW2S0CB1R00JE图片6
RW2S0CB1R00JE概述

1Ω ±5% 2W ±50ppm/℃

1 Ohms ±5% 2W Chip Resistor 4122 J-Lead Current Sense Wirewound


得捷:
RES SMD 1 OHM 5% 2W J LEAD


立创商城:
1Ω ±5% 2W


贸泽:
Wirewound Resistors - SMD 2watt 1ohm 5%


Allied Electronics:
RES SMD 1 OHM 5% 2W J LEAD


Chip1Stop:
Res Wirewound 1 Ohm 5% 2W 50ppm/ C Molded J-Lead SMD


Newark:
# OHMITE  RW2S0CB1R00JE  SMD Current Sense Resistor, 1 ohm, 2 W, ± 5%, RW Series


Electro Sonic:
Res Wirewound 1 Ohm 5% 2W ±50ppm/°C J-Lead SMD


Win Source:
RES SMD 1 OHM 5% 2W J LEAD / 1 Ohms ±5% 2W Chip Resistor 4122 J-Lead Current Sense Wirewound


RW2S0CB1R00JE中文资料参数规格
技术参数

额定电压DC 100 V

容差 ±5 %

额定功率 2 W

产品系列 RW

电阻 1 Ω

阻值偏差 ±5 %

额定电压 100 V

封装参数

安装方式 Surface Mount

引脚数 2

封装 4023

外形尺寸

长度 10.34 mm

宽度 5.74 mm

高度 5.64 mm

封装 4023

物理参数

工作温度 -55℃ ~ 150℃

温度系数 ±50 ppm/℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

RW2S0CB1R00JE引脚图与封装图
RW2S0CB1R00JE引脚图
RW2S0CB1R00JE封装图
RW2S0CB1R00JE封装焊盘图
在线购买RW2S0CB1R00JE
型号: RW2S0CB1R00JE
制造商: Ohmite
描述:1Ω ±5% 2W ±50ppm/℃
替代型号RW2S0CB1R00JE
型号/品牌 代替类型 替代型号对比

RW2S0CB1R00JE

Ohmite

当前型号

当前型号

RW2S0CB1R00JET

Ohmite

完全替代

RW2S0CB1R00JE和RW2S0CB1R00JET的区别
