RL875-101K-RC

径向引线RF扼流圈 Radial Lead RF Choke

RF Choke Bobbin Core 100uH 10% 1KHz 20Q-Factor Ferrite 890mA 280mOhm DCR RDL Bag

得捷:
FIXED IND 100UH 890MA 280MOHM TH

艾睿:
Jump-start your electrical design by including this rf choke RL875-101K-RC leaded inductor from Bourns. This part has a pitch of 5 mm. This leaded inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. It has an inductance of 100u H. This product is 7.5 mm tall with a diameter of 8.3 mm. This device is made with bobbin core technology. It has a tolerance of 10%. This leaded inductor has a maximum DC current of 890m A with a maximum resistance of 280m Ohm. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 7MTyp Hz.

Verical:
RF Choke Bobbin Core 100uH 10% 1KHz 20Q-Factor Ferrite 0.89A 0.28Ohm DCR RDL Bag

Online Components:
RF Choke Bobbin Core 100uH 10% 1KHz 20Q-Factor Ferrite 890mA 280mOhm DCR RDL Bag

Electro Sonic:
RF Choke Bobbin Core 100uH 10% 1KHz 20Q-Factor Ferrite 890mA 280mOhm DCR RDL Bag
