RL875-100M-RC

径向引线RF扼流圈 Radial Lead RF Choke

10 µH 无屏蔽 绕线 器 2.9 A 50 毫欧最大 径向，垂直圆柱（开放）

得捷:
FIXED IND 10UH 2.9A 50 MOHM TH

艾睿:
This rf choke RL875-100M-RC leaded inductor from Bourns is constructed on a core with concentric leads on opposite ends of the core. This part has a pitch of 5 mm. This leaded inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. This device is made with bobbin core technology. It has an inductance of 10u H. It has a tolerance of 20%. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 25MTyp Hz. This leaded inductor has a maximum DC current of 2.9 A with a maximum resistance of 50m Ohm. This product is 7.5 mm tall with a diameter of 8.3 mm.

Verical:
RF Choke Bobbin Core 10uH 20% 2.52MHz 35Q-Factor Ferrite 2.9A 0.05Ohm DCR RDL Bag

Electro Sonic:
RF Choke Bobbin Core 10uH 20% 2.52MHz 35Q-Factor Ferrite 2.9A 50mOhm DCR RDL Bag
