Res Thin Film 3.2 x 1.6mm 249Ω 0.1% 0.25W1/4W 25ppm/℃ Molded SMD T/R
249 Ohms ±0.1% 0.25W, 1/4W Chip Resistor 1206 3216 Metric Anti-Sulfur, Automotive AEC-Q200 Thin Film
得捷:
RES SMD 249 OHM 0.1% 1/4W 1206
立创商城:
249Ω ±0.1% 250mW
贸泽:
Thin Film Resistors - SMD 1/4W 249 Ohms 0.1% 1206 25ppm
艾睿:
Res Thin Film 1206 249 Ohm 0.1% 0.25W1/4W ±25ppm/°C Pad SMD Automotive Medical T/R
Chip1Stop:
Res Thin Film 3.2 x 1.6 mm 249 Ohm 0.1% 0.25W1/4W 25ppm/ C Molded SMD T/R
Verical:
Res Thin Film 1206 249 Ohm 0.1% 0.25W1/4W ±25ppm/C Pad SMD Automotive Medical T/R
额定电压DC 200 V
容差 ±0.1 %
额定功率 0.25 W
产品系列 RG
电阻 249 Ω
阻值偏差 ±0.1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 200 V
安装方式 Surface Mount
引脚数 2
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.4 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 155℃
温度系数 ±25 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 1000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
