SMD电阻器/芯片电阻器
SMD器/芯片电阻器
立创商城:
3.9kΩ ±5% 50mW
得捷:
RES 3.9K OHM 5% 1/20W 0201
贸泽:
Thick Film Resistors - SMD 3.9K OHM 5%
艾睿:
Use this RC0201JR-073K9L fixed single surface-mount resistor from Yageo to obtain a visually clean layout. This dependable part has a power rating of 0.05 1/20 W. This product has a resistance value of 3.9K Ohm. Its temperature coefficient is ±200 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 5%. This device is made with thick film technology. This product is 0.6 mm long, 0.23 mm tall and 0.3 mm deep. This part has an operating temperature of -55 to 125 °C.
安富利:
Res Thick Film 0201 3.9K Ohm 5% 1/20W ±200ppm/°C Molded SMD SMD Paper T/R
Chip1Stop:
Res Thick Film 0.6 x 0.3 mm 3.9K Ohm 5% 0.05W1/20W 200ppm/ C Molded SMD Paper T/R
Verical:
Res Thick Film 0201 3.9K Ohm 5% 0.05W1/20W ±200ppm/C Epoxy SMD T/R
容差 ±5 %
额定功率 0.05 W
产品系列 RC
电阻 3.9 kΩ
阻值偏差 ±5 %
工作温度Max 125 ℃
工作温度Min -55 ℃
精度 ±5 %
额定电压 25 V
安装方式 Surface Mount
封装公制 0603
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.23 mm
封装公制 0603
封装 0201
工作温度 -55℃ ~ 125℃
温度系数 ±200 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
RC0201JR-073K9L Yageo 国巨 | 当前型号 | 当前型号 |
RC0201JR-073K9 国巨 | 功能相似 | RC0201JR-073K9L和RC0201JR-073K9的区别 |
WR02X392JTL 台湾华科 | 功能相似 | RC0201JR-073K9L和WR02X392JTL的区别 |
