RHL750

RHL750图片1
RHL750图片2
RHL750图片3
RHL750图片4
RHL750概述

变阻器 25watt 750ohm 500V Locking Shaft

These rheostats are designed and manufactured to operate smoothly and reliably over long periods of use. Used for motor speed controls, light dimmers and for equipment requiring convenient variable resistance settings. Windings are linear taper on stock models. Tapered windings available as custom order. Ceramic body, high-grade resistance alloy windings, vitreous enamel coating some models silicone-ceramic, metal spring contact arm, metal graphite composition and solder coated terminals.
.
*Tolerance:** ±10%. Wattage based on 25°C.
RHL750中文资料参数规格
技术参数

容差 ±10 %

额定功率 25 W

电阻 750 Ω

封装参数

安装方式 Solder Lug

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 Non-Compliant

含铅标准 Contains Lead

海关信息

ECCN代码 EAR99

HTS代码 8533390080

数据手册

在线购买RHL750
型号: RHL750
制造商: Ohmite
描述:变阻器 25watt 750ohm 500V Locking Shaft
