4 W 单输出 5 V 短路保护 AC/DC 电源
With this AC to DC power supply from RECOM your electronic device will be able to operate by using direct current instead of alternating current. It has a voltage of 5 V and maximum output power of 4 W. This part"s single output can handle a current up to 0.8 A. This part has a temperature range of -40 °C to 70 °C.
得捷:
AC/DC CONVERTER 5V 4W
贸泽:
AC/DC电源模块 4W AC/DC 3kV REG 90-305Vin 5Vout
艾睿:
AC/DC Power Supply Single-OUT 5V 0.8A 4W 6-Pin Box
Allied Electronics:
Recom 4W, 1 Output, Embedded Switch Mode Power Supply SMPS, 5V dc, 800mA
Chip1Stop:
AC/DC Power Supply Single-OUT 5V 0.8A 4W 6-Pin
Newark:
# RECOM POWER RAC04-05SA/277 AC/DC PCB Mount Power Supply, Ultra Compact, Adjustable, 1 Output, 90 V, 305 V, 4 W, 5 V
额定功率 4 W
输出接口数 1
输出电压 5 V
输出电流 0.8 A
输出功率 4 W
输入电压DC Max 430 V
输入电压DC Min 120 V
输入电压AC Max 305 v
输入电压AC Min 90 v
输出电流Max 800 mA
输入电流Min 0.075 A
输出功率Max 4 W
额定功率Max 4 W
工作温度Max 70 ℃
工作温度Min -40 ℃
输入电压 90VAC ~ 305VAC
安装方式 Through Hole
引脚数 6
封装 DIP-7
长度 36.7 mm
宽度 27 mm
高度 36.7 mm
封装 DIP-7
重量 26.31 g
工作温度 -40℃ ~ 70℃
产品生命周期 Not Recommended for New Designs
包装方式 Box
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
