RP3SL012

TE CONNECTIVITY  RP3SL012  通用继电器, RP3SL系列, 功率, SPST常开, 12 VDC, 16 A

RP3SL 系列

120A，20ms 涌入能力

5 mm 引脚

提供 DIN 导轨安装插座，参见库存号 400-9130

应用：照明控制、计时器、电动机控制、家庭自动化

线圈功率：500 mW

工作温度范围：- 40 至 +70°C爬电距离和间隙：8 mm

绝缘线圈到触点：4000V 交流

开关电压：250 V 交流

高 25.5，宽 29，深 12.6

### 认可

UL，CSA，VDE

### 认可

UL；CSA；VDE

欧时:
SPNO PCB power relay,16A 12Vdc coil

得捷:
RELAY GEN PURPOSE SPST 16A 12V

艾睿:
Electromechanical Relay 12VDC 270Ohm 25A SPST-NO 29x12.6x25.5mm THT Power Relay

Allied Electronics:
SPST-NO PCB Mount Non-Latching Relay Through Hole, 12V dc

Chip1Stop:
Power Relay 12VDC 25A SPST-NO 29mm 12.6mm 25.5mm THT

Verical:
Electromechanical Relay 12VDC 270Ohm 25A SPST-NO 29x12.6x25.5mm THT Power Relay

Newark:
The RP3SL012 is a 1-pole general-purpose PCB Low Power Relay with DC coil, RP3SL series. 1 form-A 1NO contact configuration, AgSnO2 contact. 16A, flux-proof. 4kV/8mm coil-contact. For high inrush currents up to 120A.

MASTER:
Power Relay 12VDC 25A SPST-NO29x12.6x25.5mm THT

Online Components:
Power Relay 12VDC 25A SPST-NO29x12.6x25.5mm THT

Electro Sonic:
Power Relay 12VDC 25A SPST-NO29x12.6x25.5mm THT
