R114165000

RADIALL  R114165000  射频/同轴连接器, SMB同轴, 直角插头, 焊接, 50 ohm, RG179, RG187, RG188, RG316, 铍铜

The is a clamp SMB Right Angle Plug for use with KX22A, RG179, RG188, RG187 and RG316 RF coaxial cables. It has gold over nickel plated brass body with gold over nickel plated beryllium copper centre contact and a PTFE insulator.

.

1000MR Minimum insulation resistance

.

500Veff Minimum dielectric withstanding voltage

.

170Veff Maximum voltage rating

.

500-cycle Mating life

.

-55 to 155°C Operating temperature range
