REF02EZ

ANALOG DEVICES  REF02EZ  芯片, 串联电压基准, 5V, 15MV, 8-DIP

参考电压，5 V，Analog Devices

### 电压参考，Analog Devices

精密固定和可调电压参考 IC 利用串联、并联或串联/并联拓扑，并提供通孔和表面安装封装。 电压参考的初始准确度为 ±0.02 至 ±2%。

得捷:
IC VREF SERIES 0.3% 8CERDIP

立创商城:
5V 10mA

欧时:
参考电压，5 V，Analog Devices### 电压参考，Analog Devices精密固定和可调电压参考 IC 利用串联、并联或串联/并联拓扑，并提供通孔和表面安装封装。 电压参考的初始准确度为 ±0.02 至 ±2%。

贸泽:
参考电压 +5V PREC VOLT REFERENCE/T

艾睿:
Even in the event of large power supply variations, this REF02EZ voltage reference power management device from Analog Devices can produce and maintain a precise DC voltage. With an output that has a voltage of 5 V, this is power management at its best. Supply your circuit with sufficient power by implementing this, which does not exceed 40 V. It has an initial accuracy of 0.3%. To produce a constant current at your output, supply your circuit with a load regulation of 100ppm/mA and line regulation of 100ppm/V. This voltage reference circuit supports series topology. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It runs with a maximum temperature coefficient of 8.5ppm/°C. This voltage reference circuit has a minimum operating temperature of -40 °C and a maximum of 85 °C.

Chip1Stop:
V-Ref Precision 5V 10mA 8-Pin CDIP Tube

Verical:
V-Ref Precision 5V 10mA 8-Pin CDIP Tube

Newark:
# ANALOG DEVICES  REF02EZ  Voltage Reference, Precision, Series - Fixed, REF02 Series, 5V, DIP-8

DeviceMart:
IC VREF SERIES PREC 5V 8-CERDIP

Win Source:
IC VREF SERIES 5V 8CERDIP
