非隔离负载点直流/直流转换器, ITE, 16.5 W, 3 V, 5.5 V, 3 A, 可调, SIP
Provide the ability to switch between voltages by using this step down DC to DC converter and switching regulator module. It has a voltage of 5 V. This part has a temperature range of -40 °C to 85 °C. This device comes in tube packaging.
得捷:
DC DC CONVERTER 5V 15W
贸泽:
Non-Isolated DC/DC Converters DC/DC REG 6.5-18Vin 3.0-5.5out
e络盟:
非隔离负载点直流/直流转换器, ITE, ITE, 16.5 W, 3 V, 5.5 V, 3 A, 可调
艾睿:
Provide the ability to switch between voltages by using this step down R-535.0PA DC to DC converter and switching regulator module. It has a voltage of 5 V. This part has a temperature range of -40 °C to 85 °C. This device comes in tube packaging.
富昌:
R-5x Series 5 V 3 A Adjustable Output Voltage DC/DC Converter
Chip1Stop:
* DC/DC-Converter 'INNOLINE' SIP12 * reg Module DC-DC 1-OUT 5V 3A 12-Pin SIP Tube
Newark:
# RECOM POWER R-535.0PA Non Isolated POL DC/DC Converter, Auto Sense, Adjustable, SIP, 16.5 W, 3 V, 5.5 V, 3 A
额定功率 15 W
输出接口数 1
输出电压 5 V
输出电流 3 A
开关频率 270kHz ~ 330kHz
输入电压Max 18 V
输入电压Min 6.5 V
输入电压DC Max 18 V
输入电压DC Min 6.5 v
输出电压Max 5.5 V
输出电压Min 3 V
输出电流Max 3 A
输出功率Max 16.5 W
额定功率Max 15 W
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 6.5V ~ 18V
安装方式 Through Hole
引脚数 12
封装 SIP-12
长度 32.2 mm
宽度 9.1 mm
高度 15 mm
封装 SIP-12
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
