18位FET总线交换开关系列 18-BIT FET BUS-EXCHANGE SWITCHES
description/ordering information
The SN54CBT16209 and SN74CBT16209A devices provide 18 bits of high-speed TTL-compatible bus switching or exchanging. The low on-state resistance of the switches allows connections to be made with minimal propagation delay.
The devices operate as an 18-bit bus switch or a 9-bit bus exchanger, which provides data
exchanging between the four signal ports via the data-select S0, S1, S2 terminals.
Members of the Texas Instruments Widebus Family
5-ΩSwitch Connection Between Two Ports
TTL-Compatible Input Levels
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74CBT16209ADLR TI 德州仪器 | 当前型号 | 当前型号 |
SN74CBT16209ADL 德州仪器 | 类似代替 | SN74CBT16209ADLR和SN74CBT16209ADL的区别 |
