SSQ-108-02-T-D-RA

Conn Socket Strip SKT 16POS 2.54mm Solder RA Thru-Hole

16 Position Receptacle Connector Through Hole, Right Angle

欧时:
Tiger Buy Skt Strip w/t sq. Tails 0.100"

得捷:
CONN RCPT 16POS 0.1 TIN PCB R/A

艾睿:
Samtec&s;s socket strip SSQ-108-02-T-D-RA header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This SKT connector&s;s 16 contacts that are made out of phosphor bronze and plated with matte tin over nickel. Its pitch is 2.54 mm. It has a socket type gender. It has a right angle body orientation. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. This device has a maximum current rating of 6.3 A/contact. SSQ-108-02-T-D-RA is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. This product is 20.83 mm long, 4.95 mm tall and 12.57 mm deep.
