其他, SDS005R
Side Actuated Detect Switch
欧时:
Switch detect SMD overtravel plunger
立创商城:
检测开关 Detector Switch
得捷:
SWITCH DETECT SPST-NC 100MA 12V
贸泽:
检测开关 WHITE SIDE ACTUATED DETECT SWITCH
e络盟:
其他, SDS005R
艾睿:
This side actuated SDS005R switch detector from C&a;K Components can be used in a wide array of applications for it&s;s use of detecting changes in your environment. This device has a maximum current rating of 0.1 A @ 12VDC. This plunger actuator is 2.5 mm long. It has a SPST configuration. This switch detector has an operating temperature range of -40 °C to 85 °C. It has 2 terminals. The SDS005R switch detector has a j-bend termination style. The maximum DC voltage rating is 12 VDC. This product is 5 mm long, 2 mm tall and 8.2 mm deep.
安富利:
DETECT
Chip1Stop:
Switch Detector N.C. SPST Plunger J-Bend 0.1A 12VDC SMD T/R
Verical:
Switch Detector N.C. SPST Plunger J-Bend 0.1A 12VDC SMD T/R
MASTER:
Side Actuated Detect Switch
Online Components:
Side Actuated Detect Switch
Electro Sonic:
Side Actuated Detect Switch
Win Source:
SWITCH DETECT SPST-NC 100MA 12V / Switch SPST-NC Surface Mount, Right Angle
额定电压DC 12 V
触点类型 SPST-NC
额定电流Max 0.1A @12VDC
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压DC Max 12 V
接触电阻Max 100 mΩ
安装方式 Surface Mount
封装 SMD
长度 4 mm
宽度 4 mm
高度 2 mm
封装 SMD
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SDS005R C&K Components | 当前型号 | 当前型号 |
SDS005 C&K Components | 完全替代 | SDS005R和SDS005的区别 |
