STMicroelectronics低噪声线性电压调节器,具有低静态电流。 适用于各种应用,包括电池供电系统和电子传感器。### 线性电压调节器,STMicroelectronics
可调线性稳压器,STMicroelectronics
低噪声线性稳压器,具有低静态电流。 适用于各种应用,包括电池供电系统和电子传感器。
得捷:
IC REG LINEAR 3.3V 150MA SOT666
欧时:
STMicroelectronics STLQ015XG33R 线性稳压器, 1.5 → 5.5 V输入, 3.3 V输出, ±3%精确度, 150mA最大输出
e络盟:
固定电压稳压器, LDO, 1.5V至5.5V, 112mV压差, 3.3V输出, 150mA输出, SOT-666-6
艾睿:
Say goodbye to unstable voltages with this LDO STLQ015XG33R linear regulator from STMicroelectronics. Its typical dropout voltage at current is 0.112@150mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. It only needs a voltage of at least 1.5 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 0.002%/mATyp and line regulation of 0.01%/VTyp your circuit is capable of maintaining a constant voltage level at your output. This product will be shipped in tape and reel packaging so that components can be mounted effectively. The maximum dropout voltage is 0.3@150mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
Chip1Stop:
LDO Regulator Pos 3.3V 0.15A 6-Pin SOT-666 T/R
儒卓力:
**LDO.VREG 3,3V 0,15 A SOT666 **
力源芯城:
3.3V固定输出,0.15A,单路低压差稳压器
DeviceMart:
IC REG LDO 3.3V .15A SOT666
输出接口数 1
输出电压 3.3 V
输出电流 150 mA
针脚数 6
静态电流 2.4 µA
跌落电压 112 mV
输入电压Max 5.5 V
输入电压Min 1.5 V
输出电流Max 150 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 6
封装 SOT-666
长度 1.7 mm
宽度 1.3 mm
高度 0.6 mm
封装 SOT-666
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Power Management, 便携式器材, 消费电子产品, Portable Devices, Consumer Electronics, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
STLQ015XG33R ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
LD39015XG33R 意法半导体 | 完全替代 | STLQ015XG33R和LD39015XG33R的区别 |
NCP583XV33T2G 安森美 | 功能相似 | STLQ015XG33R和NCP583XV33T2G的区别 |
BH33PB1WHFV-TR 罗姆半导体 | 功能相似 | STLQ015XG33R和BH33PB1WHFV-TR的区别 |
