4A 至 9A,Vishay Semiconductor肖特基整流器是半导体二极管,具有极低的正向电压降和非常快的切换作用。 肖特基二极管的反向恢复时间非常快。 肖特基二极管适用于需要快速切换和低功耗的应用。### 肖特基整流器,Vishay Semiconductor
The is a surface-mount high-current density dual common cathode Schottky Rectifier with solderable matte tin-plated terminals. It is suitable for use in high frequency rectifier of switching mode power supplies, free-wheeling diodes, DC/DC converters and polarity protection application.
针脚数 2
正向电压 0.7 V
正向电流 8 A
最大正向浪涌电流(Ifsm) 120 A
正向电压Max 600 mV
正向电流Max 8 A
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温 -55℃ ~ 150℃
工作结温Max 150 ℃
安装方式 Surface Mount
引脚数 2
封装 TO-277
长度 4.75 mm
宽度 6.15 mm
高度 1.2 mm
封装 TO-277
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Automotive, Commercial, Industrial, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SS8P6C-M3/86A Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
SS8P6CHM3/87A 威世 | 功能相似 | SS8P6C-M3/86A和SS8P6CHM3/87A的区别 |
SS8P6C-M3/87A 威世 | 功能相似 | SS8P6C-M3/86A和SS8P6C-M3/87A的区别 |
SS8P6CHM3/86A 威世 | 功能相似 | SS8P6C-M3/86A和SS8P6CHM3/86A的区别 |
